Resin Reinforced Fiber Ringan, KFRP Aramid Fiber Reinforced Plastic Fiber. Kabel Optik Dukungan
Detail Produk
batang frp
,frp plastik yang diperkuat serat
KFRP Aramid Member Untuk Kabel Fiber Optik:
KFRP Memperkuat Anggota Untuk Kabel Serat Optik:
1. Spesifikasi Produk:
Φ0.40mm Φ0.50mm × Φ0.58mm
Φ0.45mm Φ0.62mm × Φ0.68mm
2. Fitur:
1) Ringan dan kekuatan tinggi: KFRP memiliki karakteristik kepadatan rendah dan kekuatan tinggi. Rasio kekuatan dan modulusnya lebih tinggi daripada kawat baja dan GFRP;
2) Ekspansi rendah: KFRP memiliki koefisien ekspansi termal yang lebih rendah daripada kawat baja dan GFRP dalam berbagai suhu;
3) Dampak dan resistensi putus: KFRP memiliki kekuatan tarik yang jauh lebih tinggi (≥ 1700Mpa). Bahkan jika rusak, kekuatan tarik yang tersisa bisa 1300Mpa;
4) Fleksibilitas yang baik: KFRP fleksibel dan mudah ditekuk. Diameter lentur minimumnya adalah 24 kali diameter batang KFRP;
5) Estetika yang baik dan fleksibel, terutama untuk tata ruang dalam ruangan.
3. Indikator kinerja teknis KFRP:
NO.ItemUnitIndex
1
Diameter
Toleransi
Bodymm ± 0,05
Lapisan
2Tidak bundaranBody% ≤5.0
Lapisan
3. Properti Bending Minimum -
Diameter lentur: 10D,
permukaan tanpa bur, retak dan pecah
4Tensile StrengthMpa≥1700
5 Modulus TarikGpa≥52
6Tekukan lentur suhu tinggi (80 ℃, 24 jam) -
Diameter lentur: 30D,
permukaan tanpa bur, retak dan pecah
7Low bending test suhu (-40 ℃, 24 jam) - Permukaan tanpa bur, retak dan pecah
Diameter 0.5mm-7.0mm Length 50km/drum. strength member Product Description:FRP Rod is a type of reinforced plastic product with high tensile strength and strong durability. It is made of high-strength composite material, which is composed of fiber and resin. The FRP Rod is available in different sizes, ranging from 0.5mm to 7.0mm in diameter, and in various shapes, including rod and flat. The length of each FRP rod is 50km/drum. The color of the FRP rod is clear. FRP rods can
Product Description: Fiber Reinforced Plastic Rods are ideal for a variety of applications due to their outstanding features. FRP rods are available in a range of colors, including clear, and lengths, from 50km/drum. The diameter of FRP rods range from 0.5mm to 7.0mm and can be shaped into rods or flats. Moreover, their tensile strength is high, making them the perfect choice for a variety of industrial and commercial applications. FRP sticks, also known as FRP poles, are an
Product Description: Fiber Reinforced Plastic Rod (FRP-Stick) is a high-performance stick-shaped rod made of fiber-reinforced plastic. It is an ideal material for many applications in various industries due to its excellent tensile strength and superior durability. The FRP-Stick-Rod is available in different shapes such as rod or flat, and can be custom manufactured to meet your specific requirements. The rod has a diameter ranging from 0.5mm to 7.0mm and length up to 50km
Product Description: Fiber Reinforced Plastic Rod, which is also known as Fiberglass Stick or FRP Rod, is a type of material that features a high tensile strength. It is made of fiber reinforced plastic and comes in rod or flat shapes with a diameter range from 0.5mm to 7.0mm. It is sold in a length of 50km/drum, which makes it an ideal material for many applications. Its high tensile strength makes it perfect for use in a wide range of industries, such as automotive,
Misi kami adalah untuk menawarkan "Kualitas Tinggi" & "Layanan Baik" & "Pengiriman Cepat" untuk membantu klien kami mendapatkan lebih banyak keuntungan.
