Kabel Fiber Glass Core FRP Memperkuat Tidak Sensitif Terhadap Kejutan Ringan Bukan Logam
Detail Produk
anggota frp
,anggota kekuatan frp
Kabel serat gelas FRP memperkuat inti
1, bahan bukan logam, tidak sensitif terhadap guncangan, berlaku untuk petir, daerah lingkungan iklim hujan
2, Kabel optik dengan inti penguat FRP dapat dipasang di sebelah kabel daya dan peralatan listrik, tidak terganggu oleh arus induktif yang dihasilkan oleh kabel daya atau peralatan listrik.
3, Dibandingkan dengan inti logam, FRP tidak akan menghasilkan gas yang dihasilkan oleh reaksi kimia antara logam dan factice, sehingga tidak akan mempengaruhi indeks transmisi serat optik.
4, Dibandingkan dengan inti logam, FRP memiliki kekuatan tarik tinggi dan ringan.
5, inti kabel serat optik FRP dapat mencegah peluru, gigi dan semut.
Spesifikasi: diameter (satuan: mm)
0,40 | 0,45 | 0,50 | 0,60 | 0,80 | 1,00 | 1.20 | 1.25 | 1.30 | 1.40 |
1,50 | 1,60 | 1.80 | 2,00 | 2.10 | 2.20 | 2.30 | 2.40 | 2,50 | 2.60 |
2.70 | 2.80 | 3,00 | 3.20 | 3.30 | 3,50 | 3.70 | 4,00 | 4,50 | 5.00 |
Panjang produk
Memeriksa barang | Parameter Teknis |
Penampilan | Tidak ada retakan dan kotoran di permukaan |
Warna | Warna alam |
Diameter luar (mm) | D ± 0,05 |
Rasio kerataan (%) | ≤5 |
Diameter luar KFRP (mm) | d ± 0,05 |
Rasio kerataan KFRP (%) | ≤20 |
Kepadatan (g / cm3) | 1.3 ～ 1.4 |
Kekuatan Tarik (Mpa) | ≥1700 |
Modul elastisitas tarik (Gpa) | ≥50 |
Perpanjangan putus (%) | ≤3.0 |
Diameter lentur minimum (mm) | ≤12 |
Tes lentur suhu tinggi | 80 ℃, 24 jam, Φ30mm, Tidak pecah |
Tingkat pelepasan lapisan (N) | ≥20 |
We develop and produce Flat FRP strength member for different application.
FRP Rod Strength Member for Fiber Optic Cables FRP Rod Strength Member for Fiber Optic Cables Strength member for fiber optic cables, usually located at the center of fiber optic cables, is one important component of fiber optic cables by supporting optic fiber bundle and enhancing cables tensile strength. FRP Rod / FRP strength member is made by thermal pultrusion technique which combines complex resin as body material with glass fiber as reinforcement at a certain ratio.
Cable Strengthen Core For Fiber Optical Cables Non-Metallic FRP Rod Central Strength Member CSM Basic Info Technique: Pultrusion Type: Themosetting Plastic Profiles Diameter Ranges: 0.40 mm to 5.00 mm HS Code: 70199090 Materials: Resin, E-glass Fiberglass, Agents, etc. Applications: Central or peripheral strength member for fiber optical cables Origin: Jiangsu, China Product Description: Non-metallic FRP Rod strength member, usually located at the center or the periphery of
FRP Rod Strength Member for Fiber Optic Cables FRP Rod Strength Member for Fiber Optic Cables Strength member for fiber optic cables, usually located at the center of fiber optic cables, is one important component of fiber optic cables by supporting optic fiber bundle and enhancing cables tensile strength. FRP Rod / FRP strength member is made by thermal pultrusion technique which combines complex resin as body material with glass fiber as reinforcement at a certain ratio.
Misi kami adalah untuk menawarkan "Kualitas Tinggi" & "Layanan Baik" & "Pengiriman Cepat" untuk membantu klien kami mendapatkan lebih banyak keuntungan.
